Reference Electrodes

Ionode's full range of reference electrodes includes calomel, gel-filled, double junction refillable and general purpose refillable models for the most discerning of research facilities … all with the Ionode pedigree. Ionode can customise reference electrodes to suit your application and supply Reference Verification Certificates upon request.

  • Easily refilled
  • Individually verified for premium performance

The Reference Range

Model Body Reference Refillable Temp. Range Connector1
IJ-14 Polypropylene Double Junction Ag/AgCl Y 0 - 60°C 4mm Banana Plug
IH-10 Polypropylene Double Junction Ag/AgCl N 0 - 60°C 4mm Banana Plug
PJFO Polypropylene Single Junction Ag/AgCl, saturated refillable KCl. Y 0 - 60°C 4mm Banana Plug
VL_Ionode004 Glass Double Junction Ag/AgCl Y 0 - 80°C 4mm Banana Plug
VL_Ionode005 Glass Hg/Hg2Cl2 Y 0 - 80°C 4mm Banana Plug
echem-ref-r Glass Single Junction Ag/AgCl Y 0 - 80°C Gold plated pin
echem-ref-r-sr* Glass Single Junction Ag/AgCl saturated KCl Y 0 - 80°C Gold plated pin
* Designed for non-aqueous measurements
1 Standard option, other connector types available
